| Power Range | 0.5 H.P. to 20 H.P. (415 V, 50Hz Ac Three Phase) |
| Speed | 2800 RPM |
| Max. Discharge | 900 LPM K-Type, 1300 LPM Q-Type |
| Max. Head | 1250 Feet K-type, 400 Feet Q-Type |
| Per Stage Head | 55 Feet K-type, 45 Feet Q-Type |
| Max. Temp. | 30° C |
| Pump Shaft | Bearing Bush | Sleeve & Couple | S.S. Strip | Impeller | Diffuser | Outlet/Suction | Cable Guard | Hardware |
| Stainless Steel | Leaded Tin Bush | Stainless Steel 410/430 | Stainless Steel 304 | Stainless Steel 410/Nylone | Stainless Steel 304/ Cast Iron | Cast Iron | Stainless Steel | Stainless Steel |
| Part Name | Shaft | Bearing Bush | Sleeves | Trust Bearing | Lower/Upper Housing Base | Copper | Stamping | Stator Shell |
| Materials | S.S. 431/410 | Leaded Tin Bronze | S.S 431/410 | S.S. Seagment and Carbon Plate | Cast Iron | Special EC Grade As Per IS Standard | C.R.N.G.O. M-45 | Stainless Steel |
